This document describes the colors palettes used in Ultima Underworld. This is highly technical behind-the-scenes info that is not useful to the typical game player.

Description

Ultima Underworld renders it's game screens in VGA (hardware mode 13h) that draws 320x200 pixels is an 8-bit paletted (256 unique colors per screen) mode. It's palette pulls from RGB colors at 6 bits per channel (18-bit true color) for a total of 262,144 unique colors. Compare that with more modern 8 bits per channel (24-bit true color) systems that have 16,777,216 colors to pick from.

Ultima Underworld has several different palettes, stored in several files. It has 8 main palettes (8-bit index, 256 colors) several 4- and 5-bit to 8-bit lookup palettes, shader lookup palettes, tranlucency lookup palettes, and palette animations/rotations. All of these things will be discussed below.

Main Palettes

The main palettes are stored in FILEData\Pals.Dat.

Each palette is 256 colors, and each color is 3 bytes, one for each channel of red, green, and blue. Though each channel only uses 6 bits, so the top 2 bits of each 8-bit byte go unused. Each palette is 768 bytes, and the file size is 6,144 bytes, so it hold exactly 8 palettes and no header or any other kind of data.

In all palettes color #0 is always the transparent color.

Palettes stored in data/pals.dat

#	Image	Where used
0		Used in the main game screen Not all colors are available in game, some are place holders for translucency look-ups Color #0 is transparent, color #1 is true black, colors #2-15 are mostly full-bright non-animated colors used for spell effects. Several rotations run at 5 per second: Fire 1, 5 colors, #16-20, move up (lower index to higher) Fire 2, 3 colors, #21-23, move up (lower index to higher) Water, 16 colors in 4 blocks of 4, #48-63, move down (higher index to lower)
1		Used in the map screen
2		Used in the title screen Rotation of 4 blocks of 16 colors, #64-127, each at 10 per second
3		Used in the character creation screen
4		Joke palette, used in the main game screen Fire and water are blacked out, all other colors are mapped to simulate the Apple II color palette
5		Used in the splash screen
6		Unknown usage, duplicate of #5
7		Used in the game win screen

All Palettes

Aside from the 8 main palettes, the game has several other palettes. These are all main screen palettes, so really they just lookup into palete #0 (and technically, palette #5)

Consider this image:

All this color data is stored in different places in the game, it is just gathered here in one image for convenient demonstration.

There are 4 blocks of colors:

1. The first block is the 8 palettes from FILEdata\pals.dat, details of those are coverd in the section above.
2. The second block has 3 sub-blocks:
   1. The first is the shades, it tells the game which color to shade a pixel when an object of the color has a certain light level on it. Notice that the fire/lava colors stay full bright all the time and that the water stays nearly full bright until the very end. This comes from FILEdata\light.dat
   2. The second is the same as the first, but it is used when the player is using a night vision spell. Notice that fire and water aren't affect by night vision's black and white palette. Notice that the fire and water aren't in grayscale and behave the same as the full color shading. This comes from FILEdata\mono.dat
   3. The third shows the palette rotations for the fire and water colors.
3. The third block has two small columns:
   1. On the left are the 4-bit palettes used to draw item sprites and other 4-bit graphics. They are found in the file FILEdata\allpals.dat.
   2. On the right are the palettes used to draw the weapon POV overlay sprites. There are only two of these, one used to draw weapons wielded by players with light colored skin and the other for dark colored skin. This comes from the file FILEdata\weapons.cm
4. The forth block has 6 color strips, mappings for 6 translucent colors: This comes from FILEdata\xfer.dat
   1. Black
   2. White
   3. Brown
   4. Green
   5. Blue
   6. Red

Critter Palettes

The 32 critter animations each contain 1 or more 5-bit palettes (32 unique colors each) that point back to the main palette. The 64 in-game critters link to combinations of these animations and their palettes. Some notes about the palettes in the following tables:

• In the main palette, color 0 is transparent and color 1 is true black. In all of these palettes that is reversed, color 0 is true black and color 1 is transparent.
• The palette column has been given a darker background for a better contrast to see the palettes with.
• To best see same animations with different paletes, click first the pal num column and then the anim name column.
• Each critter animation has 2 pages, one for combat animations and one for non-combat animations. Each of these two files has it's own palette, so techincally a critter could be colored differently while hostile than while peaceful, but this "feature" is never used and the two files always have the same palette.

obj num	npc num	npc description	anim num	anim name	pal num	palette
64	0	a_rotworm	22	rotgrub	0
65	1	a_flesh slug	9	slug	0
66	2	a_cave bat	3	bat	0
67	3	a_giant rat	16	rat	0
68	4	a_giant spider	5	spider	0
69	5	a_acid slug	9	slug	1
70	6	a_goblin	0	gngob32	0
71	7	a_goblin	14	graygob	0
72	8	a_giant rat	16	rat	1
73	9	a_vampire bat	3	bat	1
74	10	a_skeleton	1	skela	0
75	11	an_imp	18	imp	0
76	12	a_goblin	0	gngob32	1
77	13	a_goblin	0	gngob32	2
78	14	a_goblin	0	gngob32	3
79	15	—	24	batskull	0
80	16	a_goblin	14	graygob	1
81	17	a_mongbat	18	imp	1
82	18	a_bloodworm	22	rotgrub	1
83	19	a_wolf spider	5	spider	1
84	20	a_mountainman&mountainmen	27	dwarf32	0
85	21	a_green lizardman&green lizardmen	2	lizman	0
86	22	a_mountainman&mountainmen	27	dwarf32	1
87	23	a_lurker	25	Lurk	0
88	24	a_red lizardman&red lizardmen	2	lizman	1
89	25	a_gray lizardman&red lizardmen	2	lizman	2
90	26	an_outcast	26	fight32	0
91	27	a_headless&headlesses	20	hedless	0
92	28	a_dread spider	5	spider	2
93	29	a_fighter	17	femfite	0
94	30	a_fighter	17	femfite	1
95	31	a_fighter	26	fight32	3
96	32	a_troll	7	troll	0
97	33	a_ghost	13	ghost	0
98	34	a_fighter	26	fight32	1
99	35	a_ghoul	11	ghoul	0
100	36	a_ghost	13	ghost	1
101	37	a_ghost	13	ghost	2
102	38	a_gazer	6	gazer	0
103	39	a_mage	4	wiza	0
104	40	a_fighter	26	fight32	2
105	41	a_dark ghoul	11	ghoul	1
106	42	a_mage	21	wizb	0
107	43	a_mage	8	femwiz	0
108	44	a_mage	4	wiza	1
109	45	a_mage	4	wiza	2
110	46	a_ghoul	11	ghoul	2
111	47	a_feral troll	7	troll	2
112	48	a_great troll	7	troll	1
113	49	a_dire ghost	13	ghost	3
114	50	an_earth golem	19	golem	0
115	51	a_mage	21	wizb	1
116	52	a_deep lurker	25	Lurk	1
117	53	a_shadow beast	28	shadow	0
118	54	a_reaper	15	reaper	0
119	55	a_stone golem	19	golem	1
120	56	a_fire elemental	10	fire	0
121	57	a_metal golem	19	golem	2
122	58	a_wisp	23	wisp	0
123	59	—	29	tybal	0
124	60	—	12	demon	0
125	61	—	31	litening	0
126	62	—	30	eye	0
127	63	an_adventurer	26	fight32	0

Special Colors

The main palette (palette #0) has these special colors:

num	Color	Description	Example
0		this color is transparent. There is no alpha channel, any pixel in this color simply isn't drawn.
1		true black
16 23		These 8 colors are rotated (as a group of 5 and a group of 3) to make fire and lava effects
48 63		These 16 colors are rotated (as 4 groups of 4) to make flowing water effects
251		fake translucency, black used by ghosts, shadow beasts, smoke from buring things
252		fake translucency, white used by ghosts, clouds in the swamp
253		fake translucency, red not seen in game, similar effect seen in Ultima Underworld II the screenshot to the right is based on a hack to demonstrate this feature
254		fake translucency, green not seen in game the screenshot to the right is based on a hack to demonstrate this feature
255		fake translucency, blue not seen in game the screenshot to the right is based on a hack to demonstrate this feature

Notes:

• There are 5 fake translucency linking colors, but there are 6 translucency lookups in FILExfer.dat. One of them is not used.
• There are 5 fake translucency linking colors, but only the black and white ones are ever used in-game. Ultima Underworld II uses a red one for the red haunt.
• The red, green, and blue ghosts in the screenshots above do not appear in the game. They are based on a hacked version of the game to demonstrate the coded but unused feature of the game engine.

PSX Version

The PSX-port of Ultima Underworld uses an entirely different engine. It is not limited to 256 colors on-screen and as such it doesn't use any of the same palette techinques that the PC version does that are described here. The PSX version stores it's graphics files in 8-bit paletted format, but each graphic can have it's own 256 color palette and the PSX hardward can display tens or hundreds of thousands of colors on the screen at once.

For all it's advantages, the PSX version does seem to have some missing features:

• It doesn't emulate the PC's palette rotation feature, so water and fire graphics are static and unanimated. Fullsize waterfalls and lavafalls are animated by vertically scrolling the texture, but the smaller ones aren't animated at all.
• The shader doesn't seem to be programmed to make the fire/lava graphics full bright, so you can see dark fire and lava which seems odd.

•

  A campfire in the PC version of Ultima Underworld. Notice that the fire is drawn at full brightness regardless of distance or carried lights.

•

  A campfire in the PSX-port of Ultima Underworld. Notice that the fire is shaded like any other object. A "dark fire" is a strange thing to see.

•

  (PC) Judy waiting by the lava. Notice the lava is drawn at full brightness.

•

  (PSX) Judy waiting by the lava. Notice the lava is shaded like the rest of the scenery.

•

  (PC) A lava fall, rivulets of lava, and a lava floor. All are drawn full bright and animated via palette rotation.

•

  (PSX) A lava fall, rivulets of lava, and a lava floor. All are shaded like regulr textures. The lavafall is animated by vertical scrolling, the rest are not animated at all.

For more details on the differences of the PSX version, see the article Technical Differences in Ultima Underworld on the PSX

---
